MultiTest-dV Operating Manual Mecmesin 27
4. Jog Mode
Icon Action
Zero (tare) all system values.
Move the crosshead upward at the set jog speed.
Move the crosshead downward at the set jog speed.
Crosshead has reached an upper limit (load signal from a connected
gauge, set to Stop, or a limit switch) and stopped.
Crosshead has reached a lower limit (load signal from a connected gauge,
set to Stop, or a limit switch) and stopped.
5. Settings Menu
Icon Action
Confirm selection (or press the scroll wheel button).
Navigate up a menu selection or value (or turn the wheel clockwise).
Navigate down a menu selection or value (or turn the wheel
anticlockwise).
Go back to the previous screen.
