No Name Function
1 Menu title Title of menu page
2 Context depen-
dent symbol
Navigating through and choosing from
menus
3 Menu number Number of the displayed menu
4 Navigation aid Inidicates, if there are further menus
available by pushing „up“ or „down“
5 Lift up /
Lift down
Levitating/delevitating of the rotor
LED flashes green: rotor ist being levi-
tated/delevitated
LED constantly green: rotor levitating
6 Drive on /
Drive off
Starting / stopping of the motor
LED flashes orange: drive is braking.
LED constantly orange: drive is running
Function only implemented up to SW
Version 4.09
7 Mode
(abbreviated
by „M“)
Change between modes
LED flashes red: warning
LED constantly red: fault
8 Up Navigation button
No LED
9 Enter Navigation button
No LED
10 Down Navigation button
No LED
