6 TROUBLESHOOTING
6.1 Fault Categories
In order to facilitate diagnosis, all warning and fault messages
of the device supervision are assigned to one of the following 9
categories.
Fault category Description
100 IMC15 is defective
Replace IMC15
200 Sensor fault
Defective sensor cabling possible.
Check sensor cabling and installation
first.
300 Bearing magnet fault
Defective bearing magnet possible.
Check bearing cable and installation
first.
400 Motor fault
Defective motor possible. Check
motor cabling and installation first.
500 Termperature fault
Overtemperature. Check environ-
mental conditions and cabinet first.
600 Boot/Startup fault
Incorrect state of the device during
startup/powerup. Device is blocking
due to selfcheck fault.
700 Overload
Check the load.
800 Warnings and Selfcheck warnings
900 General faults during operation
