MECOS IMC15 - 8 TECHNICAL DATA; General Data

IMC15
54
8 TECHNICAL DATA
General Data
Dimensions and
weight
Heigth [mm] 409
Width [mm] 222
Depth [mm] 229
Weight [kg] 11
Electrical data Input power
[kVA]
16
Input voltage
[VAC]
400 VAC +/- 10% (EUR)
460 VAC +/- 10% (USA)
Total efficiency @
25 °C [%]
(including AMB,
input and output
filter)
94
Environmental
conditions
Temperature range
(Operation) [°C]
0 ... 55
Temperature range
(Storage) [°C]
-10 ... 60
Humidity
(maximum) [%]
85, non condensing
Height above sea
(maximum) [m]
2000
Protection class IP20 / PD2
Mounting informa-
tion
Master gauge for
mounting holes
refer to appendix
External dimen-
sions (drawing)
refer to appendix
Terminal blocks Motor and Grid:
AWG 18-6/0.82-13.3mm
2
Motor PTC (J2)
AWG 26-14/0.14-1.5mm
2
