MECOS IMC15 - Drive

8 Technical data
55
*)
Do not use any type of series choke for adaption of input
voltage or enhancement of input current quality.
**)
1100Hz at 14kW
+)
Temperature sensor incorporated into the stator windings of
the motor. Processing by IMC15: Short detection during self-
check (fault condition: RPTC < 80 Ohm), detection of cable
interruption or overtemperature during operation (fault condi-
tion: RPTC> 700 Ohm)
Drive
Input Input voltage
[VAC]
400 VAC +/- 10% (EUR)
460 VAC +/- 10% (USA)
Line frequency [Hz] 50 Hz (EUR)
60 Hz (USA)
Unsymmetry [%] 3%
Input filter (line filter) Schaffner FN 3258-30-33,
Schaffner FN 3258-30-47,
FUSS 3F460-030.270
externally connected*
)
Input fuse [A] 32A, (chap. 4.3.4)
Output Power [kW] 15
Permanent load [%] 100
Speed [Hz]
0 ... 900**
)
, continuously
Motor current [Arms] max. 29.5
Overload [%] Customer specific (Ixt
supervision)
Short / ground circuit Supervised
Output filter 2nd order (LC), built-in
General data Operating modes 2 quadrants (acceleration,
braking, field weakening in
one sense of rotation
Braking power [W] 600
Derating No derating recommended
Motor limit tempera-
ture monitoring
PTC triple-sensor according
to DIN 44082
+)
