IMC15
40
6.3 Troubleshooting Procedures
Diagnosis: Selfcheck Faults of the IMC15
No. Error Message Meaning Diagnosis Action
102
...
106
AutoECS0 ... 4 Auto eddy cur-
rent sensor0 ...4
Damage in the
analog part of
sensor signal
processing
Hardware damage Replace IMC15
107 Cap1neg Capture 1 nega-
tive
Damage in the
analog part of
sensor signal
processing
(pulse compara-
tor)
Hardware damage Replace IMC15
108 Cap1pos Capture 1 posi-
tive
refer to 107
