mectron COMPACT PIEZO LED - Consents; Footswitch Consent with Negative Signal; Footswitch Consent with Positive Signal

21
compact piezo led connections
EN
Consents

The footswitch consent must be connected to pins 10 and 7.

The footswitch consent must be connected to pins 8 and 11.
1
2
3
4
5
6
7
8
13
16
15
14
12
9
10
11
Footswitch
