compact piezo led connections
Connections

Pins 1 and 16 must be always connected.
1
2
3
4
5
6
7
8
13
16
15
14
12
9
10
11
Red
Black
Scaler handpiece cord
Violet
Gray

Connect the handpiece cord wires to terminal M2 and connector CN2 respecting the polarity
