mectron COMPACT PIEZO LED - Available Wiring Diagrams

23
compact piezo led connections
EN
Available wiring diagrams
-  Power (24V
~
or 32 V and consent are footswitch controlled.
-  Power (24V
~
or 32 V ) is supplied through the contact on the
quiver and consent is footswitch controlled.
1 2
9 16
8 7 6 5 4 3 2 1
Black
Red
Scaler handpiece cord
Blue
Blue
Solenoid valve
(optional)
24 V
2,5W
Quiver
Yellow
Yellow
Green
Green
White White
Fuse holder, fuse, footswitch
and quiver are not included in
Mectron’s supply
Potentiometer
2.2 K linear
T 2 A
Footswitch
Fuse
Supply voltage
24 V
~
50/60 Hz o
32 V
Minimum 40VA
Violet
Gray
9 16
8 7 6 5 4 3 2 1
1 2
T 2 A
Black
Red
Footswitch
Fuse
Yellow
Potentiometer
2.2 K linear
Green
White
Scaler handpiece cord
Yellow
Green
White
Fuse holder, fuse and footswitch are
not included in Mectron’s supply
Solenoid valve
(optional)
24 V 2,5W
Supply voltage
24 V
~
50/60 Hz o
32 V
Minimum 40VA
Violet
Gray
