Medeli DIGITAL DRUM - Rear Panel

6
RearPanel
DCinput
Powerswitch
MIDIINandMIDIOUT
USBport
ConnectionfortheDC9Vpoweradapter.
Thisswitchturnspoweronandoff.
Theseportsallowcommunicationwithotherproducts
equippedwithaMIDIinterface.Pleaseseethe
MIDIsectionoftheadvancedmanualfordetails.
Thisportisusedtoconnecttoacomputer
(MIDIIn/OutviaUSB).
AUXIN
Lineoutputjacks
Padinputjacks
Phonejack
Thisstereoinputjackisforanexternalsoundsourcesuchasan
MP3orCDplayer.
Stereooutputconnectiontoanaudiosystemordrumamplifier.
InputconnectionsforKick,Snare,Tom,CymbalpadsandHi-Hat
controlpedal.
Thisstereojackisusedtoconnectheadphones.
21
22
21
22
23
23
24
24
25
25
26
26
27
28
28
27
PanelControls
