Medeli DIGITAL DRUM - Initial Setup: Connecting Pads and Pedals; Pad and Pedal Connection Guide

Usingtheprovidedcables,connecteachTriggerinputjackontherearpanelofthemodule,andmakesureeach
padisconnectedtoitscorrespondingTriggerinputjack.
Note:
1.
2.
Thevoiceofhi-hatpadhittingiscontrolledbyhi-hatpedal.Similartoarealdrumkit,thehi-hatpadfunctions
asan'openhi-hat'whenthepedalisstepped.Whenthepedalisreleased,itfunctionsasa'closedhi-hat'.
Thevalidstrikingareaofacymbalpad(ride,crashorhi-hat)isneartheedgeofthepad,whichisdifferentfrom
otherpads.
Caution!
Topreventelectricshockanddamagetothedevice,makesurethepowerisswitchedOFF
onthedrumandallrelateddevicebeforemakinganyconnection.
Setup
7
ConnectthePadsandthePedals
tohi-hat
DrumModule
tosnare
toHHCTRL
Tom1
Crash1 toride
Tom2
Tom3
Tom4
Crash2
