16 man_digiflex_com_en_02_5.doc
Maximum resolution 1.25 cm for range 50 m at 50 m/µs
2.5 cm for range 50 m at 100 m/µs
2.5 cm for range 100 m
5 cm for range 200 m
10 cm for range 400 m
25 cm for range 1000 m
50 cm for range 2000 m
1 m for range 4000 m
2.5 m for range 7500 m
5 m for range 15 km
10 m for range 30 km
Accuracy ± 0.1% of range of measurement
1 cursor step
Gain 0 … 80 dB in steps of 1 dB
Dynamic range 90 dB
Distance-depending
amplitude correction
settable in 99 steps
Distance reading m, ft, or µs
Setting range of signal
propagation velocity
NVP
v
/
2
0.200 … 0.999 in steps of 0.001
30.0 … 149.9 m/s or
98.4 … 491.8 ft/s
Pulse amplitude
5 ns 2 V25 % at 120
10 ns 2 V25 % at 120
20 ns 2 V25 % at 120
50 ns 3,5 V25 % at 120
200 ns 5,0 V25 % at 120
750 ns 6,0 V25 % at 120
3 µs 6,5 V25 % at 120
