3.10 Serial Interface
The serial interface of the Digiflex Com allows reflectograms to be loaded to
an external PC or to connect a printer for printing out a hardcopy. Go to
Menu/Printer to choose from HP Deskjet, Epson 24 Needles, Epson 9
Needles, and Kodak Diconix. The Print function enables the current content
of the display to be printed by the connected printer. Moreover, the trace
just loaded can be transferred to a PC for storing and documentation
purposes provided the communication software
Winkis Com which is
available as an optional extra is installed on the PC.
Winkis Com can also
be used for re-loading a reflectogram including its set-up. Furthermore
Winkis Com gives you access to all reflectograms stored. Please refer to
the software manual if you wish to learn some more details.
The default configuration of the
Digiflex Com serial interface is
as follows:
Baud rate 9600, 8 data bits, no parity, 1 stop bit
Part of the set-up can be set in Menu/Interface.
Pin assignment of the interface cable:
Digiflex Com
9 pol.
Printer/PC
25 pol.
RX Pin 2
Pin 2 TX
TX Pin 3
Pin 3 RX
GND Pin 5
Pin 7 GND
ATTENTION
Always cover the 9-pin connector of the
Digiflex Com with
its protective cap when it is not in use. Make absolutely
sure that all test cables have been removed when the
serial interface is being used!
