42 man_digiflex_com_en_02_5.doc
Mode of
loading
Mode of display Indication
Loading Reflectogram stored in selected memory
location
A loading The reflectogram from memory is shown as a
dotted line, the reflectogram currently taken is
shown as a continuous line.
If you wish to erase the display of the trace
stored in memory, do so by using the key
combination Recall
set rotary encoder to
Erase 2
nd
trace
Mark.
,M top right in
front of Cursor
D loading Difference between current reflectogram and
reflectogram from memory
If you wish to return to the display of the
current reflectogram, do so by using the key
combination Recall
set rotary encoder to
Erase 2
nd
trace
Mark.
-M top right in
front of Cursor
Use key combination 2nd Recall for a quick download of a trace from
memory location 1.
The traces stored in memory can later be used for processing or for
printing out a hardcopy. It is also possible, however, to upload them to a
PC using the PC software program
Winkis Com which is available as an
optional extra. For printing out a reflectogram it is important first to use
Recall to load the trace from memory before pressing key Print. Another
benefit of the memory mode is that it simplifies fault locating and diagnosis.
When a number of test objects with identical cable characteristics are
tested, the entire test set-up can be taken over from a reflectogram already
stored in a memory location, so fault locating can be started without any
delay. The memory mode also allows a current reflectogram to be
compared with up to 50 reflectograms stored in memory.
