3.9 Memory Function
The Digiflex Com has 50 memory locations. This is how to save a trace:
Press key Save
Use the rotary encoder to select a free memory location or a location
that will be overwritten. The selected memory location is displayed in
inverted mode
Press key Mark
The memory window will display location number, date and time of
measurement, and parameter Range of the stored reflectogram. Parameter
Range is display according to the value of
v
/
2
or NVP which is currently set.
This has the consequence that any change of the
v
/
2
setting will also
change this value in the reflectogram. When a trace is loaded,
v
/
2
is re-set
to its stored value. In mode ALT two adjacent memory locations are made
available for storage. Memory location 1 is for quick saving triggered by key
combination 2nd Save. If mode ALT is set, quick saving will use memories
1 and 2. For this reason we suggest not to use memory locations 1 and 2
for any reflectograms which shall be retained in memory for a longer period
of time.
This is how a reflectogram is loaded from memory:
Press key Recall
Use rotary encoder to select memory location. The selected location is
display in inverted mode.
Press key Mark
Use rotary encoder to toggle between loading, A loading, and D loading
Press key Mark
