7. Spindle positioning parameters
Ones: Positioning mode selection
0: Carry
1: Indexing
Tens: Digital carry selection
0: Single-point carry
1: Multi-point carry
Hundreds: Single-point carry mode
0: Single-point one time of positioning
1: Single-point multiple positioning
(positioning times determined by the
function code)
Thousands: Single-point multiple positioning
mode
0: Reciprocating
1: Continuous
Ones: Home detector types and searching
direction settings
0, 1: Reserved
2: Homing in forward direction, ORGP as the
homing origin
3: Homing in reverse direction, ORGP as the
homing origin
4: Homing by the shortest distance, ORGP as
the homing origin
5: Homing in the current running direction,
ORGP as the homing origin
6: Searching for Z pulse in forward direction
and regard it as the homing origin
7: Searching for Z pulse in reverse direction
and regard it as the homing origin
8: Searching for Z pulse by the shortest
