31
WIKA operating instructions hydraulic high pressure controller model CPC8000-H
PN 0018708001B 11/2020 EN
EN
6. Operation
6.4.1.5 Favorites
The Favorites application provides access to up to 8 sequences. Unlike the Programs application, the Favorites does not have
a scroll wheel to cycle through all programs available. This application is primarily for programs that are frequently used. The
displayed programs can be set/saved in the Favorites application, which is accessed by selecting the Settings button then
pressing the Applications tab.
Figure 6.4.1.5 Favorites
6.4.1.6 Units and Pressure Type
The Units button is always displayed. When the Units button is pressed, a selection of imperial and metric units will be displayed on
the right. Here, the user can select which active units will be used when displaying the pressure reading on the main screen. The
Pressure Type button is a label indicating the native mode of the transducers being used (absolute or gauge). When an optional
barometer is installed, the button becomes selectable and allows the user to emulate the non-native pressure type. A native
absolute transducer will subtract the barometric reading to emulate a gauge reading, alternatively, a native gauge transducer will
add the barometric reading to emulate absolute pressure. Pressing this button will toggle between native and non-native modes.
Figure 6.4.1.6 - A Pressure Units Figure 6.4.1.6 - B Pressure Type
Pressure Units button
Pressure Type button
