WIKA operating instructions hydraulic high pressure controller, model CPC8000-H
PN 0018708001B 11/2020 EN
EN
Step- Jogs the setpoint down one step
Step+ Jogs the setpoint up one step
Step? <sp>+n.nnnnnE+nn<cr><lf> Returns the control step for the instrument
Step% Value in % of current range Sets the control step in % of current range
Steppct Value in % of current range Sets the control step in % of current range
Steppct? <sp>+n.nnnnnE+nn<cr><lf> Returns the current step in % of current range
Subunits Sets engineering units in Auxiliary Display 1. See
units text in Section 11.4
Subunits? <sp>CCCC<cr><lf> Returns Auxiliary Display 1 engineering units
in a text string.
Subunits2 Sets engineering units in Auxiliary Display 2. See
units text in Section 11.4
Subunits 2? <sp>CCCC<cr><lf> Returns Auxiliary Display 2 engineering units
in a text string.
Tare ON or OFF Tares current reading to zero. The same tare
value is applied to all measuring transducers.
Tare? <sp>+n.nnnnnE+nn<cr><lf> Returns the tare value applied to all transduc-
ers in current units.
Termchar CCC Set the termination character for the active
command set (for example the Mensor
command set will be dierent from the SCPI
command set). Accepts the following:
CRLF, CR, LF, EOI, NONE, DEFAULT
Termchar? <sp>CCCC<cr><lf> Returns the termination character.
Timeouten ON or OFF Enables the Ethernet timeout
Timeouten? <sp>(YES or NO)<cr><lf> Returns the Ethernet timeout state
Timeoutsec nnn Set the Ethernet timeout in seconds, to
automatically close the socket if no activity
has occurred. The default is 172800 seconds
(2 days).
Timeoutsec? <sp>nnnnnnn<cr><lf> Returns the Ethernet timeout in seconds
Touchcal Start the touchscreen calibration process
UNCERTAINTY? <sp>+n.nnnnnE+nn<cr><lf> Returns the current uncertainty of the
pressure reading in the active pressure units
based on the accuracy of the sensor and the
current pressure reading.
Units See units code or text in
Section 11.4
Sets the instrument engineering units. .
Units? <sp>CCCC<cr><lf> Returns the instrument units in a text string
Unitbase1 See units code or text in
Section 11.4
Sets the user 1 base engineering units.
Options are psi, bar, pascal.
Unitbase1? <sp>CCCC<cr><lf> Returns the user 1 base units in a text
string
7. Remote Operation
