WIKA operating instructions hydraulic high pressure controller model CPC8000-H
PN 0018708001B 11/2020 EN
EN
Hydraulic module
Measure/Control port max. 105 % FS
Control parameters
Control stability < 0.005 % FS
Control range 5 ... 700 bar (75 ... 10,000 psi) 20 ... 1,600 bar (290 ... 23,000 psi)
Permissible ambient conditions
Operating temperature 15 … 40 °C (59 … 104 °F)
Storage temperature 5 ... 70 °C (41 … 158 °F)
Relative humidity 0 ... 95 % r. h. (non-condensing)
Compensated temperature range 15 ... 40 °C (59 … 104 °F)
Mounting position Horizontal
Pressure controller model CPC8000-HC
Instrument
Instrument version Standard: 19" rack-mounting with side panels incl. rack-mounting kit
Optional: built into a 19" rack with CPC8000-HM hydraulic module
Warm-up time approx. 60 minutes
Dimensions in mm see technical drawings
Weight approx. 16.7 kg (37 lbs.)
Display
Screen 9.0" colour TFT with touchscreen
Resolution 4 ... 7 digits
Input methods capacitive touchscreen
Connections
Pressure connections 7/16"-20 F SAE
Pressure adapters 6 mm FITOK
®
threaded pipe connection; others on request
Filter elements all pressure ports have 40-micron lters
Permissible pressure media Dry, clean air or nitrogen
Overpressure protection Safety relief valve
Permissible pressure
Supply port 35 ... 38 bar (500 ... 550 psi)
Measure/Control port max. 105 % FS
Voltage supply
Power supply AC 100 ... 120 V / 200 … 240 V, 50/60 Hz
Power consumption 160 VA max
Permissible ambient conditions
Operating temperature 15 … 45 °C (59 … 113 °F)
Storage temperature 5 ... 70 °C (41 … 158 °F)
Relative humidity 0 ... 95 % r. h. (non-condensing)
Compensated temperature range 15 ... 45 °C (59 … 113 °F)
Mounting position Horizontal
Comunication
Interface IEEE-488.2, Ethernet, USB, RS-232
Command sets Mensor, WIKA SCPI
Response time < 100 ms
10. Specifications
