IMPORTANT: Turn both front engine mount adjustment nuts an equal amount in
direction required to align engine.
6. All Other Models:
a. Adjust front engine mounts until they rest on boat stringers.
b. Relieve hoist tension entirely and fasten both front mounts to boat stringer using ap-
propriate hardware.
c. Tighten the bottom nut to hold the engine in place. Then release the tension.
77968
a
b
c
d
77970
a
3.0L Side Mount Model
a-Engine Mount
b-Bolt
c-Lockwasher
d-Tab Washer
77913
c
b
a
V6 and V8 Models
a-Engine Mount
b-Bottom Nut - Not Visible
c-Tab
