WIRING DIAGRAMS
SERVICE MANUAL NUMBER 23
90-861326--1 MARCH 1999 Page 4E-5
A - Charging And Starting System
1-Alternator
2-Ground Stud
3-Starter Motor
4-Battery
5-Circuit Breaker
6-Starter Slave Solenoid
B - Audio Warning System
1-Oil Pressure Switch
2-Drive Unit Oil Level Bottle Switch
C - Instrumentation System
1-Oil Pressure Sender
2-Water Temperature Sender
3-Trim Sender
a-Positive (12V) Power Wire To Fuel Injection System Harness
b-Harness Connector To Fuel Injection System Harness
c-Auxiliary Tachometer Lead
d-90 Amp. System Fuse (DO NOT Remove)
