WIRING DIAGRAMS
SERVICE MANUAL NUMBER 23
90-861326--1 MARCH 1999 Page 4E-11
A - Charging And Starting System
1-Alternator
2-Ground Stud
3-Starter
4-Circuit Breaker
5-Starter Slave Solenoid
6-Neutral Safety Switch
B - Instrumentation System
1-Oil Pressure Sender
2-Accessory (Load Must Not Exceed 5 Amps)
C - Audio Warning System
1-Transmission Fluid Temperature Switch
a-Positive (12V) Power Wire To Fuel Injection System Harness
b-Harness Connector To Fuel Injection System Harness
c-Auxiliary Tachometer Lead
d-90 Amp. System Fuse (DO NOT Remove)
