HURTH V-DRIVE TRANSMISSION

SERVICE MANUAL NUMBER 23

90-861326--1 MARCH 1999 Page 8D-9

72960

50073

Typical Dual Cable - Rear Approach

a-Cable End Guide

b-Locknut And Washer (Tighten Until Bottoms Out, Then Loosen 1/2 Turn)

c-Spacer (Fits Over Bushings)

d-Bushing

e-Cable Barrel

f-Spacers (Fits Over Stud)

g-Cable Barrel Stud

h-Cable End Guide Stud
