HURTH V-DRIVE TRANSMISSION
SERVICE MANUAL NUMBER 23
90-861326--1 MARCH 1999 Page 8D-15
2. Install transmission on flywheel housing and secure with hardware shown. Torque fas-
teners to 50 lb. ft. (68 N·m).
72720
a
b
a-Bolts (2), One On Each Side
b-Locknuts (4), Two On Each Side
3. Connect seawater hoses to transmission fluid cooler and tighten hose clamps securely.
72711
a
b
a
b
a-Seawater Hoses
b-Hose Clamps
