MCM MODELS - BRAVO AND BLACKHAWK DRIVES SERVICE MANUAL NUMBER 23
Page 2A-8 90-861326--1 MARCH 1999
h. Bend tab washer down against flat on adjusting nut.
72922
a
e
b
d
c
a-Locknut
b-Adjustment Nut
c-Turn Adjustment Nut In This Direction (Counterclockwise) To Raise Front Of
Engine
d-Slotted Hole To Front Of Engine
e-Tab Washer
i. Remove alignment tool if not already removed.
12. Tighten all exhaust system hose clamps securely as follows (use two hose clamps on
each connection):
a. On Engines with Through-Prop Exhaust:
72537
b
a
a
a-Hose Clamps (Tighten Securely)
b-Exhaust Tube - Long Tube, Port Side - Short Tube, Starboard Side
