CLOSED COOLED (FRESH WATER) MODELS SERVICE MANUAL NUMBER 23

Page 6B-2 90-861326--1 MARCH 1999

Torque Specifications

Fastener Location lb-in. lb-ft Nm

Heat Exchanger End Cap 36-72 4-8

Thermostat Cover 30 41

Heat Exchanger Mounting Brackets

Hose Clamps Securely

Drain Plugs

Lubricants / Sealants / Adhesives

Description Part Number

Quicksilver 2-4-C Marine Lubricant With

Teflon

92-825407A3

Quicksilver Perfect Seal 92-34227--1

Quicksilver Liquid Neoprene 92-25711--3

Loctite Pipe Sealant With Teflon Obtain Locally

Specifications

Closed Cooling System Capacity

NOTICE

Unit Of Measurement: U.S. Quarts (Liters)

All capacities are approximate fluid measures.

MODEL ALL ENGINES

Seawater Cooling System 20 (19)

Closed Cooling System 18 (17)

Thermostat

Engine Specification

All Engines 160°F (71°C)

Pressure Cap Rating

Engine Specifications

All Engines 16 PSI (110 kPa)_
