FUEL DELIVERY SYSTEM FOR ELECTRONIC FUEL INJECTION
SERVICE MANUAL NUMBER 23
90-861326--1 MARCH 1999 Page 5A-1
FUEL SYSTEM
Section 5A - Fuel Delivery System For Electronic Fuel Injection
Table of Contents
Specifications 5A-2. . . . . . . . . . . . . . . . . . . . . . .
Tools 5A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubricants / Sealants / Adhesives 5A-2. . . . .
Torque Specifications 5A-2. . . . . . . . . . . . . . . .
Fuel Supply Connections 5A-3. . . . . . . . . . . . .
Replacement Parts Warning 5A-3. . . . . . . . . .
Precautions 5A-3. . . . . . . . . . . . . . . . . . . . . . . .
Fuel Delivery System 5A-4. . . . . . . . . . . . . . . .
Recommendations 5A-4. . . . . . . . . . . . . . . .
Special Tools 5A-6. . . . . . . . . . . . . . . . . . . . . . .
Rinda Technologies Special Tools 5A-7. . .
Cool Fuel System Exploded View 5A-8. . . . .
Fuel System Flow Diagram 5A-10. . . . . . . . . . .
Water Separating Fuel Filter 5A-11. . . . . . . . . .
Cool Fuel System Repair 5A-12. . . . . . . . . . . . .
Removal 5A-12. . . . . . . . . . . . . . . . . . . . . . . .
Disassembly 5A-13. . . . . . . . . . . . . . . . . . . . .
Reassembly 5A-13. . . . . . . . . . . . . . . . . . . . .
Installation 5A-16. . . . . . . . . . . . . . . . . . . . . . .
Vacuum Line Routing 5A-20. . . . . . . . . . . . . . . .
454/502 MPI and 8.2L MPI Models
With MEFI 1 5A-20. . . . . . . . . . . . . . . . . . . .
7.4L MPI Models With MEFI 2 5A-20. . . . . .
454/502 MPI and 8.2L MPI Models
With MEFI 3 5A-21. . . . . . . . . . . . . . . . . . . .
7.4L MPI Models With MEFI 3 5A-21. . . . . .
