IGNITION SYSTEM SERVICE MANUAL NUMBER 23

Page 4B-2 90-861326--1 MARCH 1999

Specifications

Description Specification

Ignition Timing 8° BTDC

Firing Order 1-8-4-3-6-5-7-2

Tools

Description Part Number

Timing Light 91-99379

Timing Tool (Jumper Plug) 91-805747A2

Multi-Meter / DVA Tester 91-99750A1

Mercruiser Special Timing Tool 91-805747A2

Lubricants / Sealants / Adhesives

Description Part Number

Silicone Dielectric Compound 92-802882A1

Heat Transfer Compound 92-805701, 92-805701-1

Torque Specifications

Fastener Location lb-in. lb-ft Nm

Distributor Clamp 30 40

Spark Plugs (New Cylinder Head) 22 30

Spark Plugs (All Others) 15 20
