FUEL DELIVERY SYSTEM FOR ELECTRONIC FUEL INJECTION SERVICE MANUAL NUMBER 23

Page 5A-10 90-861326--1 MARCH 1999

Fuel System Flow Diagram

74871

a-Vacuum Line To Plenum

b-Fuel Pressure Regulator

c-Fuel Cooler

d-Electric Fuel Pump

e-Water Separating Fuel Filter

f-Fuel Line from Tank

g-Direction Of Water Flow

h-Fuel Line to Fuel Pump

i-Fuel Line To Fuel Rail

j-Excess Fuel Return Line To Water Separating Fuel Filter

k-Fuel Injectors (8)

l-Fuel Rail
