MAINTENANCE SERVICE MANUAL NUMBER 23
Page 1B-60 90-861326--1 MARCH 1999
MIE (Inboard) Models
NOTICE
Refer to “Cold Weather or Extended Storage,” “Precautions,” in this section,
BEFORE proceeding.
1. Ensure that the boat is as level as possible to ensure complete draining of cooling
system.
2. Remove end caps, sealing washers and gaskets from the heat exchanger.
71515
a
b
c
d
a-Heat Exchanger
b-Sealing Washer
c-End Cap
d-Gasket
IMPORTANT: Use compressed air to blow any remaining water from the tubes in the
heat exchanger.
NOTE: With the engine level, sufficient draining of manifolds will occur when exhaust
manifold-to-thermostat housing hoses or drain plugs are removed.
3. Remove drain plugs (port and starboard) from bottom of exhaust manifolds.
74130
a
a-Drain Plug
