MONITOR 2.00
2-7
MONITOR – VERSION 2.00
Standard Information Display Screens
Oil Pressure
Displays engine oil pressure in Psi
or Bar.
Battery Voltage
Displays voltage level (condition)
of battery.
Range
Displays estimated range
based on current fuel consump-
tion and fuel remaining in the
tank that is connected to the
system. The number displayed
is an estimate of the distance
you can travel on the remaining
fuel at current boat speed.
NOTE: Two requirements to ac-
tivate this screen,
1. you must perform the fuel
tank calibration in CAL 2. Refer
to the CAL 2 Calibrations Sec-
tion.
2.You must have a speed input
device connected to the system
(paddle wheel or pitot pressure
transducer).
