MONITOR 2.00
2-19
MONITOR – VERSION 2.00
CAL 2 Calibration
Tank 1 Calibration
Once the capacities have been
entered, you need to. Select
whether you want to calibrate
fuel tank 1 ” ’t1”.
NOTE: The gauge will not let you
calibrate the fuel tank until the ca-
pacity had been entered).
1. Press the
button to select 1= on, 0 = off. Selecting “1” will
continue fuel tank calibration.
Tank 1 Calibration 0%
Setting
Have the fuel tank level at
empty.
2. Press the
button to save. Press the button to ad-
vance to 25% setting.
25 Percent Fuel to Add
Tank 1 Calibration 25%
Setting
Adding the amount of fuel shown
will raise fuel tank level to 25 per-
cent.
NOTE:The quantity of “Fuel to
Add” is determined by the fuel
tank capacity number entered
3. Add the displayed amount of fuel to the fuel tank.
4. Press the
button to save. Press the button to ad-
vance to 50% setting.
To Next Page
