Section 3 - Screen Overview and Operation
Page 26 90-8M0120668 eng MARCH 2016
Performance
Performance—displays advanced performance data: peak performance—RPM or speed and inches per revolution of the
propeller.
Trim and Tabs
Trim and tabs—displays drive trim position and position of tabs. A sensor must be installed on the tabs for this function to
display information.
Trip Log
Trip log—displays recorded trip data: total distance, total time, average speed, average fuel consumption. Trip log recorded
data can be erased and set to zero.
Navigation
Navigation—displays data relating to the installed navigation system: compass heading, longitude and latitude, time to waypoint
(TTW), bearing to waypoint (BTW), distance to waypoint (DTW), and course over ground (COG).
Generator
Generator—displays data the generator can send through a NMEA 2000 or J1939 protocol control area network: current run/
stop state, voltage—AC/DC, hertz, hours, oil pressure, and water temperature.
ECO
ECO—displays information to guide the operator to the best trim position and engine speed to achieve the best fuel economy.
NOTE: Refer to
Economy Mode
in this section for additional operating information.
Autopilot
Autopilot—displays autopilot data.
