Section 3 - Screen Overview and Operation
90-8M0120668 eng MARCH 2016 Page 29
Target Colors
Triangle Color Rules
State Color Fill value Action Image
Target not
achieved
Yellow Outline Blinking
52170
Target achieved Green Solid Continuous
52171
The following are examples of ECO RPM targets in different states.
52172
Not optimized
Optimized
The user‑selected data area will display the trim targets.
52173
