AC12
AC1200 Dual Band Wireless Router
- 19 -
5.1.2 LAN Settings
Go to Net work
→
LAN Settings, you can configure the IP parameters of the LAN on the screen as
below.
 M AC Addr e ss - The physical address of the router, as seen from the LAN. The value can't be
changed.
 LAN IP Se ttings - Select Auto or Manual. In Auto mode, the router will automatically detect
the LAN-WAN IP address confliction.
 IP Address - Enter the IP address of your router.
 Subnet Mask - An address code that determines the size of the network. Normally use
255.255.255.0 as the subnet mask.
NOTE:
1) If you change the LAN IP address, you must use the new IP
address to log in to the router.
2) If the new LAN IP address you set is not in
the same subnet with the previous one, the IP
Address Pool in the DHCP server will be configured a
utomatically, but the Virtual Server
and DMZ Host will not take effect until they are re-configured.

Mercusys ac12 Specifications

General

Product type	Tabletop router
Product color	Black
DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Antennas quantity	4
Antenna gain level (max)	5 dBi
Output current	0.85 A
Output voltage	9 V
Power source type	AC
Mobile network generation	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	CE, ROHS
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK
Package depth	288 mm
Package width	382 mm
Package height	66 mm
Package weight	640 g

Weight and Dimensions

Depth	140 mm
Width	222 mm
Height	32 mm
