Mercusys ac12 User Manual

AC12
AC1200 Dual Band Wireless Router
- 23 -
 IP Address - The assigned IP address of the computer in the LAN.
 Status - Displays whether the MAC and IP address are bound or not.
 Bind - Click to add an entry to the IP & Mac binding list.
Click Refresh to refresh all items.
To add an IP & MAC Binding entry, follow the steps below.
1. Click Add .
2. Enter the Host name.
3. Enter the M AC Address of the device.
4. Enter the IP Address that you want to bind to the MAC address.
5. Click Sav e.
To edit an existing entry, follow the steps below.
1. Find the entry in the table.
2. Click
in the Edit column.
3. Enter the parameters as you desire, then click Sav e.
To delete existing entries, select the entries in the table, then click Delete Selected.
To delete all entries, click Delete All.
5.2 2.4GHz Wireless
There are three submenus under the Wireless menu: Host Network, Guest Network and WDS
Bridging. Click any of them, and you will be able to configure the corresponding function.
5.2.1 Host Network
Go to 2.4GHz Wireless
→
Host Ne twork, you can configure the settings for the 2.4GHz wireless
host network on this page.

Mercusys ac12 Specifications

General

Product type	Tabletop router
Product color	Black
DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Antennas quantity	4
Antenna gain level (max)	5 dBi
Output current	0.85 A
Output voltage	9 V
Power source type	AC
Mobile network generation	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	CE, ROHS
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK
Package depth	288 mm
Package width	382 mm
Package height	66 mm
Package weight	640 g

Weight and Dimensions

Depth	140 mm
Width	222 mm
Height	32 mm
