Mercusys ac12 User Manual

AC12
AC1200 Dual Band Wireless Router
- 44 -
Click Re store to reset all configuration settings to their default values.
• The default IP address: 192.168.1.1
• The default Subnet Mask: 255.255.255.0
5.6.5 Backup & Restore
Go to System Tools
→
Backup & Restore, and then you can save the current configuration of the
router as a backup file and restore the configuration via a backup.
Click Backup to save all configuration settings as a backup file to your local computer.
To upgrade the router's configuration, follow the steps below.
1. Click Browse to locate and select the configuration file which you want to restore.
2. Click Re store to update the configuration with the file you have selected.
NOTE:
All your custom settings will be lost when defaults are restored.

Mercusys ac12 Specifications

General

Product type	Tabletop router
Product color	Black
DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Antennas quantity	4
Antenna gain level (max)	5 dBi
Output current	0.85 A
Output voltage	9 V
Power source type	AC
Mobile network generation	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	CE, ROHS
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK
Package depth	288 mm
Package width	382 mm
Package height	66 mm
Package weight	640 g

Weight and Dimensions

Depth	140 mm
Width	222 mm
Height	32 mm
