Turn the hand wheel toward you until the needles are
at their highest position.
Place a thick piece of fabric [such as felt] under the
presser foot. Lower the needles halfway into the
fabric.
Loosen, but do not remove the needle set screws with
the small allen screwdriver. Hold the needles with
your fingers and raise the needle bar. The needles
will remain in the fabric.
A. Overedge needleleft
B. Overedge needleright
With this machines, two needles can be inserted
to the needle clamp as shown in the drawing but only
one or two needles are to be used for sewing.
The Instruction Book refers to different needle
positions by illustrating the needle clamp at right.
Note: When both the left and right overedge needles
are inserted, the left needle will be slightly
higher than the right.
Caution:
Be sure to disconnect the machine from the
electric outlet before removing needle(s).
Hold the needle with the flat surface to the back.
Insert the needle into the needle socket as far as it
will go.
When inserting a needle, if you first lower it down
into the hole in the throat plate it will line up with the
needle socket. Then direct it upwards
Note: When inserting needles into the A or B sockets
it is necessary to loosen both A & B Allen Screws.
After inserting the needles equally tighten both
Screws.
14
Overedge left needle
Overedge right needle
Left and right
overedge needle
thread
B
To loosen
To tighten
Flat surface to the rear
B
A
Right overedge
needle thread
To Insert Needles (s)
12. HOW TO REMOVE AND INSERT
NEEDLES
Needle Position
To Remove Needle (s)
B
A
A
B
To Next Page
