Merrylock 2020 - Principal Parts Overview

16
2
1
3
4
5
6
7
8
10
9
11
12
13
14
15
1. Thread guides and holder
2. Handle
3. Left needle thread tension dial (orange)
4. Right needle thread tension dial (blue)
5. Upper looper thread tension dial (green)
6. Lower looper thread tension dial (red)
7. Spool pin
8. Throat plate
9. Cloth plate
10. Looper cover
11. Power & light switch
12. Stitch length dial
13. Hand wheel
14. Spool stand
15. Spool holder
16. Clean pocket
5
1. PRINCIPAL PARTS
