B
A
C
49
The following optional presser feet specially
prepared for this machine are available at
extra-charge.
Note: Do not use presser foot made for other
machines. Use of such presser foot may
result in interference with the needle and knife
and can be hazardous.
The snap-on type presser foot of this machine
permits easy removal and replacement.
Caution:
Be sure to disconnect the power line plug or
turn off the power switch when changing the
presser foot.
Raise presser foot and raise needle bar to its
highest position.
Press red colored lever (A) located on back of
clamp under the presser foot shank, raise presser
bar lifter to its High Lift position and while holding
the presser bar lifter in this position, remove the
presser foot plate.
Place presser foot plate on throat plate under
presser foot shank so that hinge pin (C) will fit in
slot (B) of the shank. Then lower presser bar lifter.
If presser foot plate can not be placed under
presser foot shank easily, raise presser bar lifter
to its High Lift position and while holding it in this
position, place presser foot plate under presser
foot shank. Then lower presser bar lifter.
Raise presser bar lifter and make sure the presser
foot plate is properly attached to the presser foot
shank.
Replacement
26. OPTIONAL ACCESSORIES
Snap-On Type Presser Foot
Removal
To Next Page
