53
Item Specification
Sewing speed 1,300 spm maximum
Stitch length (feed amount) 1~4 mm (standard: rolled hemming 1-2, ordinary overedge N=2.5)
Differential feed ratio 1:0.6 ~ 1:2 (with differential feed machine)
Overedge stitch width Rolled hemming 1.5 mm, ordinary overedge 3.0 ~ 7.0 mm
(standard 4 mm)
Needle bar stroke 27 mm
Pressure foot rise 4.5 mm
Needle Hax1 (130/705H)
Number of threads 2~4
Machine dimensions (mm)
Width 360
Depth 290
Height 300
Weight (kg) 7.9 kgs
29. SPECIFICATION
