19
Pass thread from back to the front through the
thread guide 1.
While holding thread with finger, pass it between
the tension discs and pull thread down to make
certain it is properly located in between the
tension discs 3.
Thread the top cover
thread guide by pulling
the thread towards the
left until it slips under
guide. Then pull thread
along the right side of
button as illustrated.
Thread the right needle as indicated 1~9.
Raise Presser foot to release Tension discs.
4
3
2
3
2
7
5
6
3
2
1
4
3
2
1
3) Threading the (Blue)Overedge Right Needle
(B on needle clamp)
9
8
To Next Page
