10cm
(4")
18
Thread the looper eye (A) from front to back.
Pull about 10cm (4 inches) of thread.
Position thread into V cutout (B) on threader.
Firmly hold thread tail with left hand and pull
Threader lever (C) up into place (D).
Turn the hand wheel toward you until the lower
looper extends out 5~10mm from the throat
plate edge.
Thread the looper area of the machine following
the red color coded thread guides 4~10.
Note: Use tweezers provided in the accessory
case to aid in threading the looper.
While holding thread with finger, pass it between
the tension discs and pull thread down to make
certain it is properly located in between the
tension discs 3.
Place the thread with the point of the tweezers
slightly from left and to the right of threading guide 4.
Place the thread with the point of the tweezers
slightly from front and to the back of threading guide 5.
4
3
2
10
9
9
D
B
A
10
C
4
5
6
7
8
5
3
4
3
8
6
7
To Next Page
