2) Threading the (Red)Lower Looper
17
Thread the top cover
thread guide by pulling
the thread towards the
left until it slips under
guide. Then pull thread
along the right side of
button as illustrated.
Thread the lower looper as indicated 1~10.
Thread the looper area of the machine following the
green color coded thread guides (4~9).
Thread the hole in the upper looper from front to
back 9. Note: Make sure thread passes behind lower
looper.
Note: Use tweezers provided in the accessory
case to aid in threading the looper.
Pull about 10cm(4 inches) of thread through the
looper and place to the back of the throat plate.
Pass thread from back to the front through the
thread guide 1.
Raise Presser foot to release Tension discs
10cm
(4")
2
2
9
8
9
5
4
8
6
7
7
9
6
5
8
4
2
3
1
10
1
To Next Page
