6.2.2 Conventional philosophy
a) Accept all
In the 'Accept all' mode the current state of all loads assigned to the
scenes is queried and stored in the touchpanel. Proceed as follows:
1. Ensure that all loads needed for the scene are in the desired state.
e.g. ceiling lamp OFF, floor lamp dimmed to 50% and roller shutters
lowered.
2. Press the scene key (e.g. 'TELEVISION'), until the messages 'Saving
scene. Please continue pressing button.' followed by 'Scene has been
saved. Please release key.' are displayed.
3. Release the key.
b) Save selectively
In the 'Save selectively' mode only the state of those loads assigned to the
scene which were operated during programming is queried and saved in
the touch-screen. The state of loads which, despite being assigned to the
scene, were not operated, is not saved, i.e. even when the scene is invoked
the state of these loads is not changed. Proceed as follows:
1. Press the scene key (e.g. 'TELEVISION'), until the messages 'Pro-
gramming mode has been activated. Please release key.' appears.
2. Release the key.
3. Operate all the loads needed for the scene and place them in the de-
sired state. e.g. ceiling lamp OFF, floor lamp dimmed to 50% and roll-
er shutters lowered.
Note that only states that have been changed will be taken into ac-
count. If, for example, at the time of programming the ceiling lamp
was switched off and if it necessarily has to be OFF in the scene, then
you must switch the ceiling lamp on and off again so that the OFF
state is stored.
4. Press the scene key again until the message 'Scene has been saved.
Please release key.' message is displayed.
You now have 4 minutes in which to adjust the load. If this
time is exceeded, programming is cancelled. You can quit the
programming mode without saving, by tapping the key brief-
ly.
