Installers manual 10.03.02-R03 (201058) EN SDA-04 (SW 5.xx) - SDA-04DCB2 (SW 22.00) Page 14 of 55
5.1.5 Configuration process
WARNING
When the SDA-04 is switched on for the first time, it does not automatically
begin the configuration process. Parameters 30, 31 and 32 must first be filled
in.
For the 2nd time and all times after that, the SDA-04 will wait +/- 4 sec. for
input from the control panel.
No input = Configuration process begins with the old settings
OK button pressed = SDA-04 delays configuration process until settings can
be adjusted and the "ESC" button is pressed
Explanation of different SDA-04 terms:
Configuration process : After switching on the power, the SDA-04
determines its endpoints and the minimum
(power/speed) settings required to move the
door.
Threshold velocity : The minimum speed measured during the
configuration process.
Boost : A large power output that is required
temporarily to start a hermetic door moving
from its closed position.
Final speed (slow) : This is the speed at which the door approaches
the end point.
Slow mode : Low speed
(If a door protection feature has been activated)
Return time : The time the door will remain open
before closing automatically
Monitoring : For each closing motion, the controller checks
whether the security sensor is still working.
