Metaflex SDA-04DCB2 - Display Codes and Troubleshooting; Troubleshooting Display Codes

Installers manual 10.03.02-R03 (201058) EN SDA-04 (SW 5.xx) - SDA-04DCB2 (SW 22.00) Page 34 of 55
9 Display codes and troubleshooting
Nr
Display 5.xx
Display 4.06
Omschrijving
*...
1
e
point blinks
2
e
point blinks
Setup on 90 Watt AC motor
.*..
2
e
point blinks
3
e
point blinks
Setup on 370 Watt AC motor
..*.
3
e
point blinks
-
Setup on 370 Watt AC motor heavy reductor
….
….
….
Idle (DCA/DCB)
-
bo
bo
Boost, extra force after closing
-
1
1
Security 1 active (safety edge)
-
2
2
Security 2 active (fotocell 1)
-
3
3
Security 3 active (fotocell 2)
Lo
Lo
Lo
Lock fault, no feedback
-
ONE-
1d
One way active
-
o1
o1
Obstruction in indentation
-
o2
o2
Obstruction during opening
-
o3
o3
Obstruction during closing
-
oc
oc
DMS activated
FF
Fire
FF
Fire cycle activated
ES
Stop
ES
Emergency stop activated
UL
unLo
uL
Emergency open activated
-
Edge
E
Edge control active: always slow
-
LL
LL
Initialisation process pending
-
Fo
Fo
Input open outside activated
-
Ho
Ho
Input half open outside activated
-
Fi
Fi
Input open inside activated
-
Hi
Hi
Input half open inside activated
-
iLoc
iL
Input lock activated
-
PS 1
-
Safety sensor 1 activated
-
PS 2
-
Safety sensor 2 activated
-
PS 3
-
Safety sensor 3 activated
-
PS 4
-
Safety sensor 4 activated
-
iLF1
-
Interlock disable functie 1 activated
-
iLF2
-
Interlock disable functie 2 activated
-
iLF3
-
Interlock disable functie 3 activated
-
iLF4
Interlock disable functie 4 activated
1
E 01 (AC)
Batt (DCB)
E 01 (AC)
Batt (DCB)
Undervoltage
Accu nearly empty
2
E 02 (AC)
E 02 (AC)
Overvoltage
3
E 03
E 03
Overcurrent or shortcircuit to ground (after
power on)
4
E 04 (AC)
E 04 (AC)
IxT monitoring motor
4
E RE (DCB)
E RE (DCB)
Reversed motor polarity
5
E 05 (AC)
E 05 (AC)
IxT monitoring inverter
6
E 06 (AC)
E 06 (AC)
Motor temperature too high
7
E 07 (AC)
E 07 (AC)
Inverter temperature too high
8
E 08
E 08
EEPROM failure or not initialized
9
E 09
E 09
Belt broken, position out of normal range
10
E 10
E 10
Initialize failed
11
E 11
E 11
Position encoder fault
12
E 12
E 12
Monitoring check photocell failed
13
E 13 (AC)
E 13 (AC)
Motor type failed: measured coil resistance not
matching
14
E 14 (AC)
E 14 (AC)
Inverter temperature high warning
15
E 15
-
Accu fault (no accu or reversed polarity)
