Installers manual 10.03.02-R03 (201058) EN SDA-04 (SW 5.xx) - SDA-04DCB2 (SW 22.00) Page 25 of 55
7.3.4 Relay Settings
When the controller is set in accordance with EN16005:
Relay 3 will be automatically configured as a monitoring relay for safety
devices. No other setting is possible.
Warning:
N.C. status of the relay will be controlled by the software and will be noticed
in the event of a power failure.
The SDA-04 controllers are fitted with 3 programmable relays.
The following functions can be set to each parameter individually:
1 = Relay switches when the door reaches the fully open position
2 = Relay switches 4 seconds before the auto-return and while it is
closing
3 = Relay switches when the door has reached the half open position
4 = Relay switches when the controller registers a fault
5 = Monitoring function – for controlling the operation of a safety device
Sensor on input 29
6 = Monitoring function – for controlling the operation of a safety device
Sensor on input 29 and 32
7 = Interlock output
8 = Relay opens for 500mSec. (pulse) when the door begins to open
9 = Relay switches when battery voltage drops below 18V (DCB2 only)
Parameter 70 : (0) Relay output 1 (multifunction relay)
0 = Active when the door is closed when combined with one of the following
Functions: Input 1 is active (lock) and/or
Input 2 is active (one way) and/or
Motor lock activation (Parameter 76-77-78)
1..11 = Please refer to legend 7.3.4.
Parameter 71 : (0) Relay 1 configuration (N.O. or N.C.)
0 = Relay is set as normally open (N.O.)
1 = Relay is set as normally closed (N.C.)
Parameter 72 : (0) Relay output 2 (multifunction relay)
0 = Active when the door is open (“Interlock”)
1..11 = Please refer to legend 7.3.4.
Parameter 73 : (0) Relay 2 configuration (N.O. or N.C.)
0 = Relay is set as normally open (N.O.)
1 = Relay is set as normally closed (N.C.)
