Installers manual 10.03.02-R03 (201058) EN SDA-04 (SW 5.xx) - SDA-04DCB2 (SW 22.00) Page 6 of 55
1 General
1.1 Introduction
This manual applies to the SDA-04 and SDA-04DCB2 controllers.
Software 5.xx and above is required for the SDA-04 and 20.0.0 for SDA 04DCB2.
(This will be shown on the display while the controller starts up)
The manual consists of 14 chapters.
The Metaflex controllers comply with current safety regulations.
Please read the mechanical and electrical safety regulations below before installing the door and/or
controller. Retain this instruction manual carefully so that it may be used for future reference at any
time.
1.2 Manufacturer/Distributor
Manufacturer: Metaflex Doors Europe BV
Ambachtsstraat 11
7120 AH Aalten
The Netherlands
www.metaflexdoors.com
Distributor:
Technical Dossier Management:
Metaflex Doors Europe BV (Product Development Department)
1.3 Service/maintenance
In case of problems, faults or questions, please contact:
* For service outside the Netherlands, please contact your local distributor.
1.4 Versions
The SDA-04 is available in 2 versions:
SDA-04 : This is suitable for controlling 3-phase AC motors.
SDA-04DCB2 : This is suitable for controlling 24V DC motors.
For technical specifications, see "TECHNICAL SPECIFICATIONS".
