Installers manual 10.03.02-R03 (201058) EN SDA-04 (SW 5.xx) - SDA-04DCB2 (SW 22.00) Page 24 of 55
Parameter 53 : (3) End speed (‘slow’) while opening
Is the door speed just before the door has fully opened, i.e. at the end of the
opening cycle. The door also has this end speed during the teaching-in process and
during a safety/security action (slow mode).
1..9 = 1 (threshold speed) to 9 (maximum opening speed of 120 mm/s)
Parameter 54 : (0) End speed (‘slow’) while closing
Equal to parameter 53, but while closing.
0 = The value of parameter 54 is equal to that of parameter 53
1..9 = 1 (threshold speed) to 9 (maximum opening speed of 120 mm/s)
Parameter 55 : (0) Extending the braking distance to the open end position
Extend the braking distance (slow close) of the door (value in cm), which makes
the door move more slowly.
0 = Function disabled
1..50 = additional braking distance (CM) including lower speed
Parameter 56 : (0) Extending the braking distance to the closed end position
Extend the braking distance (slow close) of the door (value in cm), which makes
the door move more slowly.
0 = Function disabled
1..50 = additional braking distance (CM) including lower speed
Parameter 57 : (0) Additional closing force compared with that determined during teaching-in
0 = Extra power during closing disabled
1..9 = Extra power increasing during closing
Parameter 58 : (0) Boost at the start of closing
Momentary extra boost for a door in the fully open position, which will pull the
door out of the indentation catch spring.
0 = Boost is not enabled
1..9 = Extra power increasing at the start of the closing procedure.
Parameter 59 : Reserved for future applications
